Mini Trucks
Capacity 0.4m³ to 2.4m&#179
Height Minimum 3m Clearance required for site access
Length 6.3m
Width 2.5m (0.3m extra required each side for mirrors)
Weight 10.5 tonnes loaded
Chute Length 2.5m
Chute Height 1.1m
6 Wheeler
Capacity 0.6m&#179 to 6.0m&#179
Height Minimum 4m Clearance required for site access
Length 7.3m
Width 2.5m (0.4m extra required each side for mirrors)
Weight 23 tonnes with Mass Management Accreditation
Chute Length 2.8m
Chute Height 1.6m
8 Wheeler
Capacity Max 7.2m&#179
Height Minimum 4m Clearance required for site access
Length 8m
Width 2.5m (0.4m extra required each side for mirrors)
Weight 28 tonnes with Mass Management Accreditation
Chute Length 2.8m
Chute Height 1.6m
10 Wheeler
Capacity Max 8.4m&#179
Height Minimum 4m Clearance required for site access
Length 8.8m
Width 2.5m (0.4m extra required each side for mirrors)
Weight 32 tonnes with Mass Management Accreditation
Chute Length 2.8m
Chute Height 1.6m
